SURFACE
MOUNT
FUZION PLATFORM
Fuzion® is Universal’s flagship platform, leveraging the latest generation of head and feeder technologies, and software tools for maximum performance. Fuzion solutions maximize utilization, Overall Equipment Effectiveness (OEE), and productivity while delivering the lowest cost per placement for any environment or product mix.
FUZIONOF Platform
FuzionOF™ continues Universal’s lineage of implementing odd-form solutions on a standard surface mount platform, delivering unmatched performance for a diverse range of pin-in-paste odd-form, surface mount odd-form and standard surface mount applications.
FUZION PLATFORM
For electronics manufacturers who demand an agile, flexible production model without limitations, Fuzion® is the pinnacle of platform performance. Fuzion is the industry’s most adaptable and capable platform, delivering profitable productivity for any manufacturing model from NPI to ultra-high volumes. Fuzion drives operational excellence, enabling manufacturers to build any product at any time, accelerate new product introduction and ramp to volume, and maximize utilization, quality, and yield.
- 1, 2, 4-beam variants
- Extra-capacity (XC) models with up to 272 feeder inputs
- Versatile multi-task odd-form (OF) model
- Throughput up to 66,500 cph per module
- Industry-leading cost per placement, flexibility and accuracy
- Largest board size capability
- Closed-loop processes to ensure the highest yields
- Maximum performance and utilization for any volume/product mix
- Comprehensive toolset to accelerate NPI and achieve 100% first-pass yield
- Ability to prototype on a single module
- Lowest cost of operation and ownership
Hidden Toggle
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
FUZION MODELS & SPECS
- FuzionOF – Versatile IC placement platform perfect for special processes such as Pin-in-Paste, Flip Chip and OFA
- Fuzion1-11 – Flexible IC placement platform perfect for NPI or complex SMT
- Fuzion1-30 – Superb for high-mix NPI environments and large board applications. Also a high-volume line booster.
- Fuzion2-14 – Best-in-class multi-function machine with fast placement of a wide component range for applications where flexibility and performance per line length are important
- Fuzion2-37 – A true multi-purpose platform. A versatile stand-alone prototyping solution, a flexible line balancer, or a high-performance multi-function solution.
- Fuzion2-60 – Flexible, high-speed productivity for medium-volume environments. A powerful line booster solution or high-performance small part placer.
- FuzionXC2-37 – High-capacity NPI, all-in-one, line balancer, or multifunction solution with a full component range
- FuzionXC2-60 – Cost-efficient, high-performance turret replacement or high-input chip placer
Max Throughput (cph)
FuzionOF
Fuzion1-11
Fuzion1-30
Fuzion2-14
Fuzion2-37
Fuzion2-60
FuzionXC2-37
FuzionXC2-60
Accuracy (µm) at greater than 1.00 Cpk
FuzionOF
Fuzion1-11
Fuzion1-30
Fuzion2-14
Fuzion2-37
Fuzion2-60
FuzionXC2-37
FuzionXC2-60
Max Board Size
FuzionOF
Fuzion1-11
Fuzion1-30
Fuzion2-14
Fuzion2-37
Fuzion2-60
FuzionXC2-37
FuzionXC2-60
Max Feeder Inputs (8mm)
FuzionOF
Fuzion1-11
Fuzion1-30
Fuzion2-14
Fuzion2-37
Fuzion2-60
FuzionXC2-37
FuzionXC2-60
Component Range
FuzionOF
Fuzion1-11
Fuzion1-30
Fuzion2-14
Fuzion2-37
Fuzion2-60
FuzionXC2-37
FuzionXC2-60
FUZIONOF PLATFORM
FuzionOF™ features the highest available odd-form automation throughput to reduce cycle times and eliminate bottlenecks. It handles a full range of standard SMT and non-traditional components up to 150mm square and up to 40mm tall, with 5kg placement force. With the most complete range of component handling and input types, a wide variety of standard tooling, and custom design and implementation services, FuzionOF addresses virtually any odd-form application. It also incorporates precise, repeatable, closed-loop processes that reduce defects, rework and waste. FuzionOF transforms back-end assembly into a strategic advantage.
- Single-beam platform with throughput up to 16,500 cph
- Full range of SM components to pin-in-paste and all odd parts in between
- 0201 – 55mm square (SFoV) and 150mm square (MFoV)
- Components up to 33mm tall, up to 5kg placement force
- Adjustable gripper and full array of odd-form nozzles; broad tooling portfolio
- Highest online capacity, widest range of feeder input types
- Improve output and yields vs. manual assembly; accelerate ROI with rapid payback
Hidden Toggle
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
FUZIONOF MODELS & SPECS
- FuzionOF – Versatile IC placement platform perfect for special processes such as Pin-in-Paste, Flip Chip and OFA
